4 Port Managed Industrial Grade Switch With 2 Giga Uplink SFP
Perfect Compact Switch For your Industrial networking needs
Product Features
- Industrial-Grade Design:Â Built to withstand harsh industrial environments, ensuring reliable performance under extreme conditions.
- IEEE 802.3at/af/bt Compliance:Â Supports IEEE 802.3at/af/bt PoE standards, providing efficient power delivery to connected devices.
- 1GbE Downlink Ports:Â Equipped with multiple Gigabit downlink ports for high-speed network connectivity.
- 1GbE:Â Offers reliable Gigabit uplink ports for seamless data transmission to higher-level network infrastructures.
- 1GbE SFP Slots:Â Includes Gigabit SFP slots for flexible fiber optic connectivity options.
- Layer 2 Switching:Â Operates at Layer 2 of the OSI model, ensuring efficient data packet forwarding and network management.
Comxus CX-NPA-4GS2I-L2 is an industrial-grade Power over Ethernet (PoE) switch designed to deliver robust and reliable network performance. Featuring 1GbE ports and supporting 1GbE uplinks, this switch is engineered for industrial environments where high durability and performance are critical. The CX-NPA-4GS2I-L2 provides efficient power distribution to connected devices while ensuring seamless data transmission, making it an ideal choice for demanding industrial applications.
| NETWORK PORT | 4×10/100/1000Mbps 1000Base-TX RJ45 PoE Ports |
| Port 1 support 24V/48V PoE (single port power MAX 60W) | |
| Port 2~4 support BT PoE (single port power MAX 30W) | |
| 2×1G SFP Ports | |
| 1x Console RJ45 Port | |
| ENVIRONMENT DETECTION | 1 group of input detection of environment temperature and humidity |
| PORT SPECIFICATION | 1-4 port 10/100/1000BaseT(X)auto detection, AUTO-MDI/MDI-X |
| TRANSMISSION MODE | Store and Forward (full wire speed) |
| BANDWIDTH | 56Gbps |
| PACKET FORWARDING | 14.44Mpps |
| BUFFER | 4.1M |
| TRANSMISSION DISTANCE | 10BASE-T : Cat3,4,5 UTP(≤250 meter) |
| 100BASE-TX : Cat5 or later UTP(≤100 meter) | |
| 1000BASE-TX : Cat6 or later UTP(≤1000 meter) | |
| 1000BASE-SX :62.5μm/50μm MMF(2m~550m) | |
| 1000BASE-LX :62.5μm/50μm MM(2m~550m) or 10μm SMF(2m~5000m) BIDI supported | |
| FLASH | 16M |
| RAM | 128M |
| WATT | Standby power consumption≤5W; |
| Network Full-load power consumption≤10W; | |
| Full load power consumption≤250 | |
| LED INDICATOR | 5 6:(SFP LED) |
| Port 1-4(Green=LINK LED Orange=POE LED | |
| PWR:(Power/system LED) | |
| P1:(Master power LED) | |
| P2:(Slave power LED) | |
| HW:(Ring network ON LED) | |
| POWER INPUT | 2 group of independent power input |
| SW:DC12-57V | |
| PoE:DC37-57V | |
| OPERATING TEMPERATURE/HUMIDITY | -40 +80°C 10% 90% RH No coagulation |
| INGRESS PROTECTION | IP40 |
| LIGHTNING PROTECTION LEVEL | 6KV 8/20us8KV ESD IP40 |
| WEIGHT | 0.82/1.1kg |
| DIMENSION | 157mm*115mm*40mm |
| 310mm*210mm*60mm | |
| MONITORING PLATFORM | Quick formation of ring network |
| System temperature monitoring and alarm | |
| System each channel key voltage monitoring and alarm System total current,total power monitoring and alarm All-Port network monitoring and alarm | |
| Support one group input and output signal monitoring and alarm | |
| Support one group input and output signal monitoring and alarm | |
| NETWORK PROTOCOL | IEEE 802.3x |
| IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z | |
| IEEE 802.3ad | |
| IEEE 802.3q, IEEE 802.3q/p | |
| IEEE 802.1w, IEEE 802.1d, IEEE 802.1S | |
| EEE 802.3z 1000BASE-X | |
| STP(Spanning Tree Protocol) | |
| RSTP/MSTP( Rapid Spanning Tree Protocol) | |
| EPPS ring network protocol | |
| EAPS ring network protocol | |
| ERPS | |
| MAC | 8K |
| VLAN CONFIGURATION | Support port-based VLAN |
| Up to 4096 VLANs | |
| Support Voice VLAN, can configure Qos for voice data 802.1Q VLAN | |
| SPANNING TREE | STP(Spanning tree protocol) |
| RSTP/MSTP(Rapid spanning tree protocol) | |
| EPPS/EAPS(Ring network protocol) 802.1x | |
| PORT AGGREGATION | Support 8 groups of aggregation, each group support up to 8 ports; |
| PORT MIRRORING | Support many-to-one port mirroring |
| LOOP GUARD | Support loop protection, real-time detection, quick alram, concise location, Intelligent blocking, automatic recovery |
| PORT ISOLATION | Support downlink ports isolate from each other and communicate with uplink port as well |
| FLOW CONTROL | Half duplex based on Back pressure; |
| Full duplex based on PAUSE frame | |
| SPEED LIMITATION | Bandwidth management based on port input and output |
| MULTICAST CONTROL | IGMPv1/2/3 and MLDv1/2 Snooping GMRP protocol registration |
| IGMPv1/2/3 and MLDv1/2 Snooping | |
| GMRPprotocol registration | |
| Multicast address management, multicast VLAN, multicast routing port, static multicast address | |
| DHCP | DHCP Snooping |
| STORM SUPPRESSION | Support unknown unicast, multicast, unknown multicast, broadcast type storm suppression Storm suppression based on bandwidth adjustment and storm filtering |
| SECURITY | Support User port+IP address+MAC address ACL based on IP, MAC Support security properties of number of MAC address based on port |
| QOS | 802.1p port queue priority algorithm Cos/Tos,QOS remark |
| WRR(Weighted Round Robin), weighted priority rotation algorithm | |
| WRR, SP, WFQ priority scheduling modes | |
| CABLE SEQUENCE | Auto-MDIX; auto detection on straight-through and cross-over cable |
| NEGOTIATION MODE | Port support auto negotiation function(self-negotiation transmission rate and duplex mode) |
| SYSTEM MAINTENANCE | Upgrade package |
| upload System log viewing | |
| WEBrecovery factory configuration | |
| PoE Function (Only For PoE models) | Port switch |
| Schedule arrangement, timing switch Voltage, current, power display | |
| System total power display and configuration | |
| PoEdog: support auto reset, timing reset and ip binding reset when device failed | |
| Port power configuration(AF.AT HiPoE.BT) | |
| Indication of over power Port | |
| PoE type configuration(48V/24V power supplying) | |
| NETWORK MANAGEMENT | WEB interface management |
| CLI management based on Telnet, TFTIP, Console | |
| SNMP V1/V2/V3 management | |
| RMONV1/V2 management | |
| RMON management | |
| INSTALLATION | DIN guide rail type(additional wall hangers) |
| CASE | Standard |
| STANDARDS | |
| EMI | CISPR 32, FCC Part 15B Class A |
| CE, FCC & RoHS | CE, FCC complaint, RoHS Compliant (pb free) |
| EMS STANDARDS | IEC 61000-4-2 |
| IEC 61000-4-3 | |
| IEC 61000-4-4 | |
| IEC 61000-4-5 | |
| IEC 61000-4-6 | |
| IEC 61000-4-8 | |
| IEC 61000-4-11 | |
| ENVIRONMENTAL | IEC 60068-2-1 |
| IEC 60068-2-2 | |
| IEC 60068-2-3 | |
| EMC | EN55032/35, EN61000-6-2/-6-4, NEMA TS2 |
| SHOCK | IEC 60068-2-27 |
| FREEFALL | IEC 60068-2-31 |
| VIBRATION | IEC 60068-2-6 |
